Oilfield Solids Control System: API Drilling Equipment

Anyone who's worked on drill rig knows: mud is the bloodstream. Too many solids, and you get higher pump pressure, slower ROP, or worse, stuck pipe and hole collapse. The reliable oilfield solids control system isn't optional. It has to run, separate, and survive long hours under heavy load.

TR Solids Control has supplied systems to hundreds of contractors. One thing we see often: people pick equipment purely on price, without checking if it really meets API drilling equipment standards. Months later, shaker screens wobble, hydrocyclone liners wear through, the centrifuge shakes badly. The downtime cost ends up far higher than the money "saved" on cheap system.

How Many Stages Do You Actually Need?

Shallow land wells? Three stages usually work: shaker + desander + desilter. Deep wells, horizontal wells, or shale gas? You need four or five stages, with decanter centrifuge at the end. A five‑stage system controls harmful solids down to 2 microns, you'll see the difference in ROP and mud condition.

Our typical oilfield solids control system includes:

• Shale shaker (API screens, adjustable cut point)


• Desander with underflow screen


• Desilter

• Decanter centrifuge (VFD, high speed, for barite recovery or fine solids removal)

• Everything is built to API drilling equipment specs – material, welding, dynamic balancing, all follow API procedures.

Why API Standards Aren't Just Paper

Some suppliers say "meets API requirements" but only match screen mesh size. Genuine API compliance (API 7K, API 13C) means: shaker vibratory force is reliable, centrifuge bowl material is proven, screens are interchangeable without changing cut points. Every system from TR Solids Control comes with full API documentation. Without those papers, you don't get past the gate in the Middle East, Russia, or North America.

Real Case: Oman Project

Last year a drilling company in Oman had a broken centrifuge, plugged desilter, and was dumping 40 m³ of fresh water daily just to dilute mud. We installed five‑stage system: three API shakers + two mud cleaners + two VFD centrifuges. After two months:

• Fresh water makeup dropped 38%

• Waste haul‑off decreased 45%

• Average ROP increased 12%

The project manager said: "If we had switched to this oilfield solids control system six months earlier, we'd have saved a ton of money."

Small Details That Get Overlooked

• Centrifuge speed – low for barite recovery, high for fine solids. Many drillers don't adjust it.

• Shaker screen checks – inspect every 4‑6 hours. A torn screen for two days will kill your desander and centrifuge.

• Hydrocyclone discharge – if underflow isn't spraying like an umbrella, it's plugged or pressure is wrong. Stop and fix it.

TR Solids Control trains your crew on these basics. All API drilling equipment spare parts are in stock, with 48‑hour emergency shipping to major drilling regions.

How to Get the Right System

Don't blindly chase a five‑stage system. Tell us: well depth, mud type, max flow rate, solids loading. We'll recommend:

• How many shakers (two+one standby is typical)


• Whether you need a separate centrifuge skid


• Tank sizes and layout

The whole oilfield solids control system can be skid‑mounted, lift and move without field disassembly. We've shipped to the Middle East, Southeast Asia, Africa, and Latin America, all with API drilling equipment certification.

If your current system is inefficient, constantly broken, or you're starting a new project, contact TR Solids Control. We'll send a detailed proposal and an API‑compliant quote. Two weeks of running will prove it.
